Sandvik CH870 Cone Crusher Parts

Sandvik CH870 Cone Crusher Parts

Product Item:81

  • Product Detail
  • FAQs

Matec Solutions is specialized in manufacturing of crusher wear parts which are 100% compatible with Sandvik CH/CS Cone Crusher Spare Parts. Reliable cone crusher spare parts enable stable production without unexpected downtime.

Matec Solutions help customers save total cost of ownership with reliable performance and durable wear life, we are the only supplier who promise full life cycle quality warranty, we take care of our customer and products at any time.

Sandvik CH870 Cone Crusher Parts List:

Model Part No Description
CH870 452.0675 Bottom shell
CH870 442.7907 Boss
CH870 452.1191 Wearing plates
CH870 452.0795 Bottom shell bushing
CH870 452.0808 Eccentric wearing plate
CH870 452.1066 Pinion shaft arm liner
CH870 452.1064 Foot
CH870 452.1065 Narrow arm liner
CH870 442.5904 Fixing plate
CH870 442.9651 Mounting plate
CH870 452.0540 Eccentric
CH870 452.0516 Hub
CH870 452.0902 Ring
CH870 442.9610 Key
CH870 452.1063 Key
CH870 452.0806 Eccentric bushing
CH870 452.0970 Hydroset cylinder
CH870 452.0969 Hydroset cylinder bushing
CH870 452.0990 Packing clamp plate
CH870 452.0972 Hydroset cylinder cover
CH870 452.0727 Pinion shaft
CH870 452.0657 Pinion shaft housing
CH870 442.9809 Wear ring
CH870 442.9808 Spacer
CH870 442.9260 Outer bearing cover
CH870 452.4426 Main shaft
CH870 452.0505 Main shaft sleeve
CH870 452.0930 Inner head nut
CH870 452.0938 Burning ring
CH870 452.0936 Head nut
CH870 452.0924 Dust seal ring
CH870 452.0921 Retaining ring
CH870 452.0891 Filler ring
CH870 452.2269 Filler ring
CH870 452.0898 Filler ring
CH870 452.0838 Concave
CH870 452.2253 Concave
CH870 452.1754 Concave
CH870 452.0842 Concave
CH870 452.0841 Concave
CH870 452.0840 Concave
CH870 452.0837 Mantle
CH870 452.0872 Mantle
CH870 452.0845 Mantle
CH870 452.4900 Mantle
CH870 452.1943 Wearing plates assembly
CH870 452.0710 Wearing plate
CH870 452.0664 Top shell
CH870 452.1060 Arm shield
CH870 452.0553 Spider cap
CH870 452.1619 Spider bushing
CH870 452.1599 Seal ring
CH870 452.0550 Ring
CH870 452.0549 Retaining ring
CH870 452.0687 Support ring
CH870 442.9353 Sleeve
CH870 442.9354 Washer
CH870 442.9979 Washer
CH870 452.0926 Dust collar
CH870 452.0999 Ring
CH870 452.0834 Locating bar
CH870 452.1267 Gasket
CH870 452.1000 Inner dust seal ring
